UPS备用电源

Model

SP-24V-2KW

Nominal Voltage(Vdc)

25.6

Nominal Capacity

50.4Ah

Series and Parallels

8S14P

Max. Continuous Output Current(A)

75

Max. Continuous Output Power(kW)

2

Charging voltage(Vdc)

29.2

Output Voltage of Battery Pack(Vdc)

20~29.2

Charging current

0.5C(max) , 0.2C(typical)

Recommend charge operation temperature range

0~45

Output Protection

Fuse

Typical Recharge Time(90%capacity)

2~2.5hours@25A， 5hours@10A

Typical Discharge Time

35min@2kW ,70min@1kW,105min@0.5kW

Typical Life Time

3~8 years,depending on the usage

Typical Cycle Time

2000 cycles(80%DOD,3500cycles(50%DOD), depending on discharge current and ambient temp

Dimensions W X H X D （mm）

440*86.5*460(2U)

Net Weight(kg)

16

Operating Temperature (max)

0 to 45℃

Operating Humidity

RH≤70% Non-Condensing

Storage Temperature (max)

0 to 40°C （short-term storage）, 15 to 25℃ (long-stem storage) , 80% of full capacity

Storage Humidity

RH≤70% Non-Condensing
